POPCORN PRODUCTION LINE C300

POPCORN PRODUCTION LINE C300 .

Equipped with a system similar to the American system for popping popcorn and the latest flavoring systems to ensure a high quality product with Capacity up to 250 kg /h

POPCORN PRODUCTION LINE C300 consists of the following parts:

1. POPCORN MACHINE
2. THE SIEVE
3. SEASSONING DRUM
4. FLAVOR PUMP
5. SPIRAL FEEDER WITH TANK
6. CONVEYOR
7. OIL AND FLAVOR MIXER

Technical specifications of the line:

1 -POPCORN MACHINE:

The process of making popcorn and blowing corn grains is done by hot air without oil
Exactly matching the American model CRETORS
Manufactured and equipped for continuous work 24/7
Length / 220 / cm, width / 100 / cm, height / 180 / cm.
Production capacity / 120 / to / 130/kg per hour,
The machine operates with open circuit system (continuous flow)
Equipped with Belgian screwdrivers, a precision control and calibration industry
Powered By LPG gas (on request)
It is equipped with Burners Italian ECOFLAM brand
Equipped with a / 12 / cm insulation layer of glass fiber over the whole structure area
Made entirely of / stainless steel 304 /.
Equipped with a main engine capacity of / 4 / hp / 3 / kW Turkish industry.
Equipped with a rotary engine capacity of 1 hp Turkish industry GAMAK brand with a Gearbox from the Italian company VARVEL.
Total capacity / 3 / kW / 380 / V / 50 / Hz
Equipped with a Stainless steel control panel, all control, protection and protection parts are supplied by SCHNEIDER brand France.
Features a touch control screen with Two languages English, Persian.
Equipped with / 2 / temperature clock, a Korean brand of AUTONICS precise tuning and calibration
Equipped with / 2 / air temperature sensors Italian industry

2 -THE SIEVE:

Length / 200 / cm, diameter / 80 / cm, width / 100 / cm
drum made of stainless steel perforated, allowing the passage of unexploded corn beads and assembled in a secondary tank carried by a strong structure made of stainless-steel profile
Equipped for work and rotation quickly proportional to the blast head
Equipped with a rotary engine capacity of 1 hp Turkish industry GAMAK brand with a Gearbox from the Italian company VARVEL
The sieve is equipped with a cooling mechanism by compressed air model Italian
Total capacity / 37 / kW / 380 / V / 50 / Hz

3 – SEASSONING DRUM :

Function: mixing the chips grains with flavor and oil
Length : / 3 /m
outer diameter / 85 /cm.
Made of (stainless steel 304)
(The Engine ) : from company) GAMAK- TURKEY)
(Gearbox) : from company (VARVEL-ITALY)
The seasoning speed is controlled electronically by an inverter / 1.5 / kW – LS brand.
The process of the scales is designed so as to prevent the accumulation and the agglomeration of the flavor
It can automatically calibrate the sloping to control the time of the chips that passes inside.
It is equipped with the following:
It is equipped with a flavor sprayer – an advanced American model which can be calibrated.
a chrome cover by the exit side of the material; it can be opened and closed for easy cleaning.
a chrome cover by the exit side of the material; it can be opened and closed for easy cleaning.

4- FLAVOR PUMP:

Function: sucking the oil and flavor from the mixers and pump them into the flavoring machine
AMERICAN MODEL:
Made of: (Stainless Steel 304)
(Gearbox) : (VARVEL-ITALY)
It is equipped with the following
(Integrated Gearbox Motor) connected with a pump mad of .of solid European aluminum.
The connection is done by coupling rubber for easy maintenance and cleaning.
Silicone food hose – made in Spain.
The amount of flavor or taste is controlled electronically by control panel and inverter the (LS -KOREA)
Wheels and Carrier platform made of (Stainless Steel 304).

5- SPIRAL FEEDER WITH TANK:

SPIRAL FEEDER WITH TANK

6- CONVEYOR:

Function: Transfer the material from the Extruder to the oven
Made of: (Stainless Steel 304) thickness 2
(The Engine): (GAMAK- TURKEY)

7- OIL AND FLAVOR MIXER:

Number of mixers is / 1 /
Function: mixing oil and flavor and spraying it by the pump
The capacity of mixer is /200/ kg.
Made of (Stainless Steel 304) :
( The Engine ) : (GAMAK-TURKEY)
(Gearbox) : ( VARVEL-ITALY)
Shape: Concave cylindrical tank for easy cleaning
It is equipped with the following:
Double-jacketed for indirect heating.
Heat clock to control hot water temperature in blenders.
Mixers are installed on a solid base made of (Stainless Steel 304) Hot water level indicator inside.
It is equipped with wheels for easy movement and cleaning.
The oil mixer floor is designed in concave form for easy cleaning.
