STUFFED CORN CHIPS LCK160

182 views

LCK160 Stuffed corn chips production Lines Contain of the following parts:

Corn Mixer :

  • Vertical Corn mixer size 300 kg made of 304 stainless steel and 2 mm thickness 3 hp motor Italian.
  • Dashboard for control.
  • Equipped with mechanical safety.
  • Electrical safety to stop working during cleaning and maintenance.
  • Equipped with special mechanism to pull the metal impurities if it found.
  • Provided with water tank for hydration.

Spiral Feeder for the Extruder

  • Spiral feeder for the extruder 60 kg size made of 304 stainless steel and 2 mm thickness.
  • Equipped with safety system to stop working during cleaning and maintenance.
  • Provide the materials to the extruder automatically 1hp motor Italian.

Extruder

  • Extruder made of thermal coated iron and covered with 304 Stainless steel.
  • Extruder Motor 40 hp Italian German privilege.
  • Inverter to control engine speed electronically brand LS (Korea).
  • Multi-speed knife to control of chips pies length with inverter and stuffing device.
  • Main screw to feed compressor equipped with motor.
  • Heater device electronically controlled by heater thermostat brand AUTONICS (Korea).
  • Inverter for speed control LS brand.
  • Production capacity 125-160 –depends on the product type mixer equipped with control panel made of stainless steel to control all operations -start-stop-temperature control.

Chocolate Cooking Tank

  • Chocolate cooking tank /kong/(500kg) double jacket and warming by water.
  • All part made of 304 stainless steel, 8mm internal thickness, 4mm external thickness, 15mm internal floor thickness.
  • Pump to rotate the water through the double jacket.
  • The pump equipped with 10hp/55 cycle motor Italian.
  • The mixer equipped with dashboard to ON / OFF and temperature control AUTONICS brand (Korea).
  • Heater device electronically controlled by heater thermostat.
  • Equipped with metal balls to grinding chocolate.

Relaxing and Stuffing Mixer Tank (500 KG)

  • Made of 304 stainless steel double jacket and warming by water, 4mm internal thickness, 4mm external thickness, 6mm internal floor thickness.
  • Heater device electronically controlled by heater thermostat.
  • Mixer equipped with speed pump to rotate the water in the double jacket.
  • Main motor 5hp/55 cycle YALMIZ brand (Turkey).
  • The mixer equipped with chocolate pump 2 hp (Turkish).
  • The mixer equipped with dashboard to ON / OFF and temperature control AUTONICS brand (Korea).

Butter Melting Tank (300kg)

  • Made of 304 stainless steel double jacket and warming by water, 4mm internal thickness, 4mm external thickness, 4mm internal floor thickness. Heater device electronically controlled by heater thermostat.
  • Same the stuffing mixer tank but the mixer motor is 2 hp/40 cycle.
  • The mixer equipped with dashboard to ON / OFF and temperature control AUTONICS brand (Korea).

Cooling Belt

  • Cooling belt made of stainless steel and equipped with fans to cooling the chips before packaging.
  • Made of European PVC or polyamide-weather resistant.
  • Provider with fan on the top of belt to cooling the product.
  • All switches and contactors European industry brand (Schneider).
    All inverters LS brand (Korea).
  • All machines manufactured in our company holds the international quality certificate ISO 9001, ISO 14001, ISO1 8001.
  • All machines manufactured in our company holds a certificate of CE.



Specifications
Model LCK 160
Production Type Stuffed Corn Ships
Production Capacity 140-160 kg/h
Stages 9 stages
Motors 11 motors
Power Requirement 66 k.w
Electricity 380v, 50 Hz
Dimensions
Length (m) 8.9
Width (m) 4
Height (m) 3.25
Quality & Certifications
Quality Assurance ISO 9001, ISO 14001, ISO 18001
CE Certified yes
